A shallow console piano that combines a permanent three-pedal setup with a relatively compact cabinet.
Who I would put this on the shortlist for
A household that wants furniture-style stability but has limited depth available. Compare its pedal response and keyboard feel with other consoles, not just its footprint.
What to check before buying
The damper is specified in two levels plus off, not the continuously variable design used on the AP-550. Confirm delivery, assembly and whether the particular package includes a bench.
Some links are affiliate links. As an Amazon Associate I earn from qualifying purchases.
Listed by the manufacturer for the US market when checked; dealer stock, finishes, bundles and regional features must be confirmed before purchase.
From the service side
My technician’s perspective
Ownership advice — not an exact-model repair report
This entry is based on published specifications and practical ownership considerations. No exact-model, first-hand repair case is being claimed here. For a problem with a Casio you already own, send me the full model number, what the instrument does, and whether the symptom occurs through headphones as well as the speakers.
Casio AP-S200 specifications
Manufacturer specifications unless a source states otherwise. Unknown details stay unverified. Model and finish variants may differ.
- Number of keys
- 88
- Keyboard action
- Smart Scaled Hammer Action
- Piano sound engine
- Multi-dimensional Morphing AiR
- Maximum polyphony
- 192
- Voices / tones
- 19
- Amplifier output
- 20 W × 2
- Weight (manufacturer configuration)
- 34.0 kg
- Dimensions: W × D × H
- 1393 × 299 × 802 mm; without music stand
- USB MIDI
- Yes — USB-B
- USB audio interface to a computer
- Not listed — USB MIDI and flash-drive audio are distinct
- Bluetooth audio input
- Yes — via included WU-BT10 adapter
- Bluetooth MIDI
- Yes — via included WU-BT10 adapter
- 5-pin DIN MIDI
- No
- Dedicated line outputs
- No dedicated line outputs listed; headphone/output sockets
- Headphone sockets
- 2 × 6.35 mm stereo
- Pedals and half-pedaling
- Three fixed pedals; damper 2 levels plus off
- Onboard recording
- 2-track MIDI; USB-drive WAV recording
- Battery operation
- No — AC power
- Included / optional setup
- Cabinet, pedals and WU-BT10; confirm bench bundle
- Other useful features
- Not verified
Related advice and repair articles
Sources and scope
Technical data checked 2026-09-22. This is an editorial buying guide, not a laboratory test or a measured reliability study. No exact-model repair is implied unless identified above.
- Casio specifications and product information (manufacturer)
